PROEL introduces the S Series, a new range of compact and powerful sub-woofers designed to complement PROEL full-range speakers. The variety of size, power and SPL offered by the four active S models provides, at an unbeatable price point, the perfect low extension solution for any speaker model available in the PROEL range.
All the S models feature high-excursion woofers in a Hybrid Band Pass configuration (HBP). This innovative design provides a higher efficiency compared to direct radiation sub-woofers and, in addition, guarantees a much better coupling of the tuning ducts with the external air, reducing the distortion and the air turbulence, for a more defined sound and deep and punchy lows.
The new CLASS D amplifier modules with SMPS (Switch Mode Power Supply) can generate a massive amount of continuous power in a compact, lightweight and reliable package. All the modules include a STEREO pre-amp section, 24dB/oct. crossover filters with selectable frequency and PHASE reverse switch.
The cabinets are built with 15/18mm plywood and finished with extra-durable polyurethane paint. They feature two flush handles and four sturdy 75mm wheels for an easy transport (S15 and S18 only).
- Compact active HBP sub-woofer
- 18” woofer with 4” VC for a deep and extended response
- 1200 W peak power
- STEREO input, link and output
- SPL MAX 131 dB
- Frequency response 36 Hz - 140 Hz
|System type||Hybrid Band Pass subwoofer|
|Loudspeaker||18'' woofer with 4" VC|
|Amplifier Continuous Power||600 W|
|Frequency Response||36 Hz - 140 Hz|
|Max SPL||131 dB|
|Connectors||IN: 2 x NEUTRIK COMBO|
|OUT: 2 x NEUTRIK XLR-M|
|LINK: 2 x NEUTRIK XLR-M|
|Controls||Volume, GND lift|
|X-over Frequency, Phase|
|Power Supply||230 VAC or 120 VAC 50/60 Hz|
|Weight||36 kg (79.4 lb)|
|Cabinet||15/18 mm plywood|
|Black anti-scratch paint|
|1.5 mm metal grille|
|1 x pole socket|
|4 x 75 mm wheels|
|Dimensions (W x H x D)||508x630x645 (745 with wheels) mm|
