Description

Club Beam 100
Led beam moving head
1X100W white led
1 wheel 14 Colors
1 wheel 17 gobos
3 facet rotating prism
DMX control
  • Model: SG CLBEAM100
  • Weight: 9.50Kg
  • EAN: 8032496649670
  • This product has a minimum quantity of 1
Light source1x100W white led high brightness
Color temperature 5600K
LED lifespan: >50.000h
LED Refresh frequency: >400Hz flicker-free
Optic systemBeam angle: 4°
Electronic focus
Luminous flux: 21300 lux @5mt (4°)
Color systemColor wheel with 14 colors + white
EffectsGobo wheel: 17 fixed gobos
Bidirectional gobo scroll with adjustable speed
8-facet rotating prism with adjustable speed
Color rainbow effect in both directions
Linear dimmer 0 - 100%
High speed electronic strobe max.25 flashes/s, with adjustable speed
Random strobe and pulse dimmer effects with adjustable speed
Control and programming2 DMX configurations available: 10/12 channels
Protocol USITT DMX 512
Pan&Tilt 8/16 bit selectable
Master / Slave mode
Sound mode with adjustable microphone sensitivity
Auto mode with 7 internal programs selectable from display
Reset via DMX
Structure and cabinetBlack aluminium/metal Housing, and plastic materials with high resistance
Red LED display
3 different Pan&Tilt angle presets: PAN 360°-540°-630°, TILT 90°-180°-270°
Mounting points with 1 omega holder
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit
3-poles XLR in/out connection
IP Rating: IP 20
Forced air fan cooling system with electronic control
Power supplyInput Voltage: AC~100-240V 50/60Hz
Switching power supply unit
Max power: 120W @ 230VAC
IN power connection with powerCON sockets
Power supply cable 1,5 mt included
Weight and dimensionsNet weight: 7,3 kg
Dimensions:: 270x149x364 mm
