Archer B1 - KIT

Light source

• Metal Halide Lamp Osram SIRIUS HRI 100W

• Color temperature: 9200K

Optics

• Projection angle zoom from 2,5 °

• Electronic focus

• Brightness: 40.000 LUX@10m

Color system

• Color wheel 12 dichroic filters + white (CTO – CTB)

Effects

• Fixed gobo wheel with 13 static gobos (9 gobos + 4 beam reducers)

• Gobo scroll effects at variable speed

• Circular prism 8 facet with bidirectional rotation and indexable

• Linear prism 5 facet with bidirectional rotation and indexable

• Frost filter

• Linear dimmer from 0 to 100

• High speed strobe effect

• Random strobo effect

Control and programming

• 2 DMX configurations available: 14/16 channels

• Control signal USITT DMX512

• Wireless DMX by Wireless Solution ready (kit not included)

• Selectable 8/16bit Pan & Tilt resolution

• Function reset controlled by DMX control

Structure and cabinet

• Metal internal structure with hi-resistance ABS cover

• High resolution LCD colour display

• Pan angle 540°

• Tilt angle 270°

• Mounting points 1 pairs of 1/4-turn locks omega older

• Automatic repositioning of Pan and Tilt

• Pan&Tilt movement lock system

• XLR 3-poles DMX IN/OUT connection

• IP rating 20

• Controlled cooling system

Power supply

• Input Voltage: AC~100-240V 50/60Hz

• Switching power supply unit

• Max power: 160W @ 230VAC

• Power connection with PowerCon IN/OUT connectors

Weight and dimensions

• Net weight: 9 kg

• Dimensions (L x A x P): mm. 260x400x181
