EK100BM
EK100BM
Description
The EK100BM is a compact, low profile professional phantom powered condenser microphone. It is characterized by an extended and linear frequency response. This elegantly designed microphone can be used by placing it both on a table and on a wall.
- Model: EK100BM
- Weight: 0.83Kg
- Dimensions: 21.00cm x 17.00cm x 6.00cm
- EAN: 8032496468219
- This product has a minimum quantity of 1
EK100Bm is a professional low profile condenser phantom powered compact microphone. This microphone has an extended and flat frequency response.
This elegantly shaped microphone can be used on a table or wall mounted.
It features a mini-XLR output connector and it's supplied with a 8 mt. XLR cable.
- Low-profile Condenser Boundary Microphone
- Half-space unidirectional polar pattern
- Wide dynamic range
- 50 Hz -18 KHz frequency response
- Phantom power requirements 9-52V
- Mini 3 pin - xlr connector
- 8mt lenght cable included
| Element | Back Electret Condenser |
| Polar Pattern | Uni-directional |
| Frequency response | 60Hz-16kHz |
| Sensibility | -48dB±3dB (0dB=1V/Pa @ 1kHz) |
| Output impedance | 600 Ω |
| Max Imput SPL | 105 dB (at 1KHz<1% T.H.D.) |
| S/N ratio | 67 dB (1KHz@1Pa) |
| Power Requirement | 48 V Phantom Power |
| Cable length | 8 m |
| Weight (Kg) | 0,25 without cable |
| Dimension | 75 x 100 x 20 mm |
| Color | Black |
