EK100BM

EK100BM
EK100BM

Description

The EK100BM is a compact, low profile professional phantom powered condenser microphone. It is characterized by an extended and linear frequency response. This elegantly designed microphone can be used by placing it both on a table and on a wall.

  • Model: EK100BM
  • Weight: 0.83Kg
  • Dimensions: 21.00cm x 17.00cm x 6.00cm
  • EAN: 8032496468219
  • This product has a minimum quantity of 1
Compare this Product

EK100Bm is a professional low profile condenser phantom powered compact microphone. This microphone has an extended and flat frequency response.

This elegantly shaped microphone can be used on a table or wall mounted.

It features a mini-XLR output connector and it's supplied with a 8 mt. XLR cable.

  • Low-profile Condenser Boundary Microphone
  • Half-space unidirectional polar pattern
  • Wide dynamic range
  • 50 Hz -18 KHz frequency response
  • Phantom power requirements 9-52V
  • Mini 3 pin - xlr connector
  • 8mt lenght cable included
ElementBack Electret Condenser
Polar PatternUni-directional
Frequency response60Hz-16kHz
Sensibility-48dB±3dB (0dB=1V/Pa @ 1kHz)
Output impedance600 Ω
Max Imput SPL105 dB (at 1KHz<1% T.H.D.)
S/N ratio67 dB (1KHz@1Pa)
Power Requirement48 V Phantom Power
Cable length8 m
Weight (Kg)0,25 without cable
Dimension75 x 100 x 20 mm
ColorBlack
