Blok EVO 2FX
Description
Blok EVO 2FX
Dual RGBAL LED source blinder
2x400W source
2 × Tunable White LED strips
Beam angle: 50° without lenses, 37° with Fresnel lens and 45° with frost lens
IP65 protection rating
DMX control
- Model: SG BLOKEVO2FX
- Weight: 14.00
- EAN: 8032496929918
- This product has a minimum quantity of 1
High-power modular LED blinder with dual sources and advanced effects control
The BLOK EVO 2FX is the high-performance model of the BLOK EVO family, designed for professional applications where light output, creative control, and
operational flexibility are essential. The dual 400W RGBAL COB source, combined with 16-section Tunable White strips, allows for highly advanced lighting management, ideal for live shows,
television, corporate events, set design, and installations with a strong visual impact.
Thanks to the integrated connection system, multiple units can be combined to create matrix arrays, dynamic light surfaces, and advanced graphic effects.
| Light source | 2 × 400 W
RGBAL COB LED 2 × Tunable White linear LED strips with 8 individual sections CRI/Ra≥84 |
| Optic system | Beam angle: 50° without lenses,
37° with Fresnel lens and 45° with frost lens Luminous flux of FULL ON: 1126 lx @ 5m without lenses Luminous flux of FULL ON: 1630 lx @ 5m with 37° Fresnel lens Luminous flux of FULL ON: 930lux @ 5m with 45° frost lens |
| Color system | RGBAL LEDs (cells) Warm White 2400K and Cold White 4900K LEDs (strips) |
| Effects | 16-bit dimmer Dimmer curves: 4 selectable dimming curves available Halogen dimming speed emulation Red Shift function (tungsten dim-to-warm emulation) High speed electronic strobe, pulse, single sectors FX with adjustable speed, duration and rate 26 dynamic patterns with adjustable speed, direction and fades Virtual color wheel with 109 numeric gel filters presets CTC from 1750K to 20000K (cells) CTC from Warm White to Cold White (strips) Selectable PWM: adjustable from 1000 Hz to 25 KHz Emergency mode: editable dimmer level, color or color temperature when DMX signal is lost |
| Control and programming | 25 DMX channel modes Protocol USITT DMX 512, RDM Strips and cells mapping swap via DMX Master/Slave mode |
| Structure and cabinet | Die cast aluminium housing LCD graphic display Quick-release anchor points, on-board mechanics for stacking multiple devices Pan directional adjustment for each cell: +/- 20° with manual control Mounting points: 2 pairs of 1/4-turn locks omega bracket IP rating: IP65 DMX 5-poles XLR IN/OUT IP65 connectors Low-noise controlled cooling system |
| Power supply | Input
Voltage: AC~100-240V, 50/60 Hz Switching power supply unit Max power: 700W @ 230VAC Seetronic X Series IP65 Power Connectors IN/OUT Power supply cable 1,0 mt included |
| Weight and dimensions | Net weight:
9,0 kg Dimensions: 400x200x200 mm (without bracket) |
