Huracan Panel

Name: Huracan Strobe Panel
Brand: SDJ
Availability: InStock

Huracan Panel

Huracan Panel

1350X0.5W RGBW SMD led

30 RGBW sectors

Beam angle 120°x120°

IP65

Light source	1350x0,5W SMD 5050 RGBW LEDs LED lifespan: > 50.000h
Optic system	Beam Angle: 120° Luminous flux of RED: 58,3 lux @ 5m Luminous flux of GREEN: 139,4 lux @ 5m Luminous flux of BLUE: 41,7 lux @ 5m Luminous flux of WHITE: 281,0 lux @ 5m Luminous flux of FULL ON: 461,1 lux @ 5m
Color system	Led RGBW
Effects	Electronic dimmer 0-100% High speed electronic strobe, pulse, single sectors FX with adjustable speed, duration and rate 30 controllable sections 127 dynamic and static patterns with adjustable speed and fades Foreground and background virtual colour wheels CTC from 2500K to 10000K Color macros selectable via DMX
Control and programming	4 DMX configurations available: 4/6/15/120 channels Protocol USITT DMX 512, RDM Plate sectors mapping swap by DMX Master/Slave mode
Structure and cabinet	Die cast aluminium housing LED display red color Front tempered glass Mounting points: 2 pairs of 1/4-turn locks omega bracket IP rating: IP65 DMX 3-poles XLR IN/OUT IP65 connectors Forced air cooling system with electronic fans control
Power supply	Input Voltage: AC~100-240V, 50/60 Hz Switching power supply unit Max power: 360W @ 230VAC Seetronic X Series IP65 Power Connectors IN/OUT Power supply cable 1,0 mt included
Weight and dimensions	Net weight: 11,7 kg Dimensions: 525x145x280(h) mm
