JBar 16
Description
JBar 16
16 led bar
12X10W led RGBW
IP65
DMX control
- Model: SG JBAR16
- Weight: 6.00Kg
- EAN: 8032496927976
- This product has a minimum quantity of 1
| Light source | 16x10W led RGBW Full Color LED lifespan: >50.000h LED refresh frequency: >400Hz flicker free |
| Optic system | Beam angle: 25° Illuminance: 1350 lux @5mt (25°) |
| Color system | LED source 4 in 1 RGBW Full
Color Infinite chromatic possibilities and colour temperature control 50 color macros can be recalled by DMX |
| Effects | Linear Dimmer 0-100% Electronic strobe: 1-20 flashes/s with adjustable speed |
| Control and programming | 6 DMX configurations available:
2/3/5/11/32/39 channels “Double pixel” control system Protocol USITT DMX 512 Master / Slave mode Static color mode with independent adjustment of strobe Automatic mode with 13 different programs selectable from the display with independent adjustment of the speed and strobe Color mode with 50 different pre-programmed color macros with independent adjustment of the strobe |
| Structure and cabinet | Aliminum housing, black
color Color LCD graphic display Mounting points: single bracket for suspension “Light up” positioning with angle adjustment 3-poles XLR in/out connection IP rating: IP 65 |
| Power supply | Input Voltage: AC~100-240V
50/60Hz Switching power supply unit Power consumption 120W Power IN/OUT connection with Seetronic X Series IP65 IN/OUT socket Power supply cable 1,5 mt included Max 6 pcs linkable @240V |
| Weight and dimensions | Net weight: 6 kg Dimensions: 1004x95x163 (h) mm |
